Cessna Citation CJ4 series interior cabin size, seat map and 3D tour

17 ft 4 in long, 4 ft 10 in wide and 4 ft 9 in high, as the manufacturer publishes it for the Citation CJ4 Gen2. Cabin length is usually measured from the cockpit divider to the aft pressure bulkhead or baggage door, so it includes the galley and lavatory.

Not fully upright. At 4 ft 9 in the Citation CJ4 cabin is 15 in short of 6 ft, so most adults stoop to move about; seated, there is room to work and sleep.

The Citation CJ4 is published for up to 9 passengers. A typical executive completion seats 6, arranged as a club of four facing seats and a pair of forward-facing seats. Owners choose their own completion, so a given aircraft may seat fewer in larger seats or carry a divan that converts to a bed.

Yes. The typical layout has aft lavatory and a forward refreshment center.

Illustrated conventional CJ4 / CJ4 Gen2 completion: six main chairs and a two-place side-facing couch, plus two cockpit seats, forward refreshment center and aft lavatory. Fuselage cutaway only. This page shows 3 seat maps: switch between them above the comparison. Every aircraft is completed to its owner's order, so these are representative layouts, not any one aircraft's.

The Citation CJ4 cabin is 3 in narrower than the Learjet 45's, 2 in lower and 2 ft 5 in shorter (4 ft 9 in high, 4 ft 10 in wide, 17 ft 4 in long against 4 ft 11 in, 5 ft 1 in, 19 ft 9 in).

It is Radar's illustration of the type, built from the published cabin length, width and height with a representative 6-seat layout for its size. Seats, materials and monuments differ from aircraft to aircraft. No manufacturer artwork, photographs or logos are used.
